ON
OFF
4. Bank selector switch
Make sure that the microphone is identical
to the wireless receiver in the bank number.
5. channel selector switch
Make sure that the microphone is identical
to the wireless receiver in the channel
number.
6. Maintenance port
Not used.
note
Never open the rubber cover.
7. encryption indicator
Lit: Encryption ON
Unlit: Encryption OFF
[Battery case internals – front]
4
5
[Battery case internals – side]
6
12
7
8
9
10
11
8. encryption setting switch
9. code setting switch [0 – 9]
10. transmission output changeover switch
[h/l]
H: 10 mW
L: 1 mW
11. Battery compartment
Insert and use a dedicated rechargeable
battery or AA alkaline batteries.
12. Microphone sensitivity selector switch
[h/l]
H: 0 dB
L: –10 dB
