Numeric Keypad - ZENEC ZE-NC5010 Handbuch

1. POWER
Press the POWER/MUTE-Button to turn
on the unit.
2. EJECT
Press the EJECT-Button to insert or eject
a disc.
3. MUTE
Press the MUTE-Button to mute the
audio output.
4. SRC
Press the SRC-Button
between the following playing modes:
RADIO Disc
DVBT SD CARD
CAMERA
The selected playing mode will be
displayed on the screen.

5. NUMERIC KEYPAD

Directly access to track/chapter or
preset station.
6. VOL UP
Increase the volume.
7. VOL DOWN
Decrease the volume.
8. INFO
Display the available disc information.
9. GOTO SEARCH
Position search function for
CD/DVD mode.
10. STOP/BAND
Change in radio mode between the
following radio bands: FM-1, FM-2,
FM-3, AM-1, AM-2
Stop playback in other playing modes.
11. SELECT
Enter the equalizer menu.
12. ESC
Leave menus and input dialogs.
13. MAIN MENU
Enter the main menu.
14. PIC
Brightness adjustment
15. REPEAT A-->B
Set start point A and end point B to
repeat continually.
to change
NAVI AV IN
iPod USB
16. OK
Start or pause the playback.
Con rm the selected adjustment.
17. DIRECTION BUTTONS
Up/Down/Left/Right to select an item
to adjust.
18. TITLE
Enter the title menu of the DVD.
19. ROOT
Enter the main menu of the DVD.
Turn on PBC while playing VCD.
20. REPEAT
Press the REPEAT-Button to repeat the
track/folder/chapter/disc playback.
21. NEXT
Press the NEXT-Button to choose the
next track/chapter.
Press the NEXT-Button in radio mode to
auto search up.
22. PREVIOUS
Press the PREVIOUS-Button to choose
the previous track/chapter.
Press the PREVIOUS-Button in radio
mode to auto search down.
23. FAST REVERSE
Fast reverse
("2X", "4X", "8X", "16X"). Radio: Decrease
frequency stepwise.
24. FAST FORWARD
Fast forward
(2X", "4X", "8X", "16X"). Radio: Increase
frequency stepwise.
25. AUDIO
Change the audio language for DVD
playback (if available).
26. ZOOM
Zooming in/out an image ("+1", "+2",
"+3", "OFF")
27. ANGLE
Change between different angles for a
scene (if available).
28. SUB-T
Language selection for DVD subtitle
(if available).
