When all devices have the same address, all the units will "listen" to the control
signal on one particular channel. In other words: changing the settings of one
channel will affect all devices simultaneously. If you set individual addresses, each
device will "listen" to a separate channel number. Changing the settings of one
channel will only affect the device in question.
DMX Channel Values
Refer to page 3 of this manual.
6.6

Remote Control

Black Out
Press this button to black out the current active mode. Press again to return.
Auto
1. Press <AUTO>.
2. Press <+> or <-> to choose the different programmes.
Sound
1. Press <SOUND>.
2. Press <+> or <-> to choose the different programmes.
Strobe
1. Press <STROBE>.
2. Press <+> or <-> to choose the different programmes.
Speed
1. Press <SPEED>.
2. Press <+> or <-> to adjust the programme speed.
Sensitivity
1. Press <SENSITIVITY>.
2. Press <+> or <-> to adjust the microphone sensitivity.
DMX/%
Allows you to activate/de-activate the DMX mode.
Manual
1. Press <MANUAL>.
2. Press <R>, <G> <B>, <W>, <A> or <UV> to select your colour.
3. Press <0> to select SMD light.
4. Press <+> or <-> to select the static colours.
Fade
Press <FADE> to enable or disable the fader.
1-9
Press <1> to <9> to adjust the colour intensity.
7.

Cleaning and Maintenance

Before starting any cleaning or maintenance activities:
1. Unplug the device's power cord from the outlet.
2. Let the device cool down.
Cleaning

Use normal glass cleaner and a soft cloth to wipe off the outside casing.

Always be sure to dry all parts completely before plugging the device back in.

Cleaning frequency depends on the environment in which the unit operates (i.e.
smoke, fog residue, dust, dew).

Do not immerse the device in any liquid.
V. 02 – 15/06/2018
HQLP10015
11 ©Velleman nv
