Handling and operation

Operation

The appliance has three operating modes:
Standby
The appliance switches automatically into standby mode (energy
saving mode) if no movement has occurred within the monitoring
area for about 30 seconds. In the case of movement occuring, the
appliance automatically detects the entrance or exit, and switches
itself on again.
Entrance
On entrance into the garage the appliance switches itself on with the
light sequence green - yellow - red.
Exit
Should a vehicle remove itself from close to the appliance, the yellow
LED 4 switches on and then the green LED
♦ Switch the appliance on by sliding the on/off switch
position "ON". The LEDs fl ash briefl y (red, yellow, green).
The appliance is now operational and the green LED
permanently.
♦ Now test the functionality by moving slowly towards the ultra-
sonic sensor
Parking Lamp
Light signal
green
yellow
red
UPA 500 A1
and checking the individual light signals of the
7
.
Distance from ultrasonic sensor
approx. 5 - 1.5 m
approx. 1.5 - 0.5 m
approx. 0.5 - 0 m
5 .
2 to the
5
