2. CONNECTION
FIRST
1
• Make all connections securely.
• Any unused connections should be insulated with electrical insulation tape.
2
Disconnect the cable from the negative terminal of the car battery.
Memo • On cars fitted with computers and other such devices (e.g. head units with
security code), you may loose the memory when disconnecting the negative lead.
3
Connect
CAUTION – PLEASE FOLLOW THE INSTRUCTIONS CAREFULLY.
result in fire, accident or electrical shock.
• CONNECTIONS FOR RCA INPUT
Blue/White
Yellow
RCA lead
(sold separately)
Remote turn on extension lead
Black
Yellow
Pre-out
Remote turn on
Ground connection
FUSE
Battery extension lead *
20A
Failure to do so may
Head Unit
EN
7
