Environmental Protection

Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
local authority or retailer for recycling advice

Description of Symbols

The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.
Read instruction Manual.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Double insulated for additional protection.
Conforms to relevant legislation and safety
standards.

Declaration of Conformity

The Undersigned: Mr Philip Ellis as authorized by: GMC
Declare that:
PRODUCT CODE: PPM
DESCRIPTION: Magnesium Palm Planer
Electric power: 230-240V~ 50Hz 420W
CONFORMS TO THE FOLLOWING DIRECTIVES:
• Directive 2004/108/EC Electromagnetic Compatability
• Directive 2006/95/EC Low Voltage Directive
• Directive 98/37/EC Machinery Directive
• Directive 2002/95/EC RoHS
• EN 60745-2-14:2003+A1:2007+A11:2007, EN 60745-1:2006
• EN 55014-1:2006, EN55014-2:1997+A1:2001
• EN 61000-3-2:2006, EN61000-3-3:1995+A1:2001+A2:2005
THE TECHNICAL DOCUMENTATION IS KEPT BY GMC
Date: 25/7/09
Signed by:
Mr Philip Ellis, Managing Director

Specifications

Nominal voltage:
Input power:
No load speed:
Planing width:
Planing depth:
Net weight:
Insulation class:
Noise and Vibration Data:
A Weighted Sound Pressure: 76.6dB(A)
A Weighted Sound Power:
Uncertainty:
Typical Weighted Vibration: 7.47m/s
Uncertainty:
The sound intensity level for the operator may exceed
85dB(A) and sound protection measures are necessary
3
230–240V~ 50Hz
420W
14000min
-1
60mm
0.1–1.5mm
2.1kg
Double insulated
87.6dB(A)
3dB(A)
2
1.5m/s
2
GB
