– (#07 footrest) Slide in footrest until you hear
an audible click. Check footrest is secured by
pulling it downwards.
– To remove footrest, press button located on
the end of the footrest attached to the seat
unit, whilst sliding the footrest out toward the
back of seat unit.
– The footrest has three height positions. Press
the button on the back of the footrest, whilst
sliding footrest up or down to your desired
position. The footrest is locked into position
when you hear an audible click. Check
footrest is secured by pulling it downwards.
c2 - c4 Safety Bar, Seat Pad & Safety Harness
Assembly
– (#05 seat pad, #06 safety harness) Put
shoulder straps through the seat pad slits at
the desired height setting.
– Put waist straps through the seat pad side slits.
– Place seat pad onto the seat unit; secure onto
velcro.
– (#10 seat unit) Behind the seat pad, slide the
buckle on the end of the shoulder straps into
the buckle slots located on the inner face of
seat unit. Check the straps are secured by
pulling on the straps.
– (#09 storage compartment) Behind the seat
pad, pull open the storage compartment door
located on the inner face of seat unit. Slide
the buckle on the end of the waist straps into
the buckle slots on either side of the storage
compartment. Close the compartment door.
Check the straps are secured by pulling on
the straps.
6
– (#11 safety bar) Place 'C' shaped clips located
on either side of the safety bar onto the side
posts and lock into position. You will hear an
audible click.
– Press down firmly on both sides of the safety
bar to ensure secure. The 'C' shaped clips
should be flush with the side posts.
– Place buckle on the end of the crotch strap
into the base of crotch bar, then slide into
seat unit. (The strap and buckle must not be
twisted or inverted. This will ensure correct
locking of the harness.)
– Adjust the length of the harness straps until it
fits firmly around your child.
WARNING:
Always use the safety harness.
To remove the seat pad & safety harness for
cleaning, follow the instructions given in the care
& maintenance section of this instruction guide.
c5 Using and Adjusting the Safety Harness
Locking the safety harness:
Lock the harness by pushing the tongues on
the ends of the waist straps, connected with the
ends of the shoulder straps, into the buckle on
the crotch strap.
The harness will automatically lock when the
tongues have been fully pushed in. You will hear
an audible click.
Unlocking the safety harness:
Squeeze the ends of the tongues together and
then slide them out of the buckle.
