Installation and Operating Guide

Sample Output Configurations

Stereo Preset Bank: Presets designed for full range stereo operation.
Stereo Full Range
Example: Stereo input with stereo output to two Panaray
Preset
Inputs:
A: Left from mixer
B: Right from mixer
Routing:
Channel 1:
(default)
Channel 2:
Channel 3:
Channel 4:
Page 30 Installation and Operating Guide
802
®
802-III Left Full Range
802-III Right Full Range
802-III Left Full Range (not used in setup below)
802-III Right Full Range (not used in setup below)
Series III loudspeakers.
®
