Betriebsanleitung | Operating instructions
Smart Pneumatics Monitor, Gateway
Smart Pneumatics Monitor, Gateway
SPM
R412026734/2019-07, Replaces: 2019-04, DE/EN

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Aventics SPM

  • Seite 1 Betriebsanleitung | Operating instructions Smart Pneumatics Monitor, Gateway Smart Pneumatics Monitor, Gateway R412026734/2019-07, Replaces: 2019-04, DE/EN...
  • Seite 2: Zu Dieser Dokumentation

    W Systemhandbuch des Buskopplers (nur auf CD) Bestimmungsgemäße Verwendung W Anlagendokumentation Der Smart Pneumatics Monitor (SPM) dient zum Anschluss eines Wenn pneumatische Komponenten im Ventilsystem vorhanden AV-Ventilsystems an ein IT-System. Er hat die Funktion eines sind: Gateways. An der seriellen Schnittstelle (RS422-Interface) des...
  • Seite 3: Allgemeine Hinweise Zu Sachschäden Und Produktschäden

    Sie das Produkt montieren. Sichern Sie die Anlage gegen Wiedereinschalten. Pflichten des Betreibers Als Betreiber der Anlage, die mit Modulen der Serie SPM ausgestattet werden soll, sind Sie dafür verantwortlich, W dass die bestimmungsgemäße Verwendung sichergestellt ist, W dass das Bedienpersonal regelmäßig unterwiesen wird,...
  • Seite 4: Identifikation Des Produkts

    Schließen Sie den SPM wie in Abb. 2 dargestellt an. +24V DC Abb. 3: Login mit Benutzername und Kennwort Im nun folgenden Einstellmenü (siehe Abb. 4) können Sie den SPM konfigurieren. Die Details dazu finden Sie auf dem beiliegenden USB-Stick in der Datei „SPM_Accessing_Configuration“.
  • Seite 5: Technische Daten

    You can also find all instructions for the AV valve system Programmieru Node RED and the AES components on the CD R412018133. All ng für Nodes für AV-Ventilsystem instructions for the SPM can be found on the USB stick. Internet of Things Presentation of information IP-Adressen Static, DHCP, AutoIP, UPnP...
  • Seite 6: Notes On Safety

    The serial interface of the SPM (RS422 interface) may only be Protect the system from being switched on. connected to the SPM interface of the AV valve system. Only one Ethernet connection in accordance with IEEE 802 may be connected to the system's two Ethernet interfaces.
  • Seite 7: About This Product

    To directly connect the SPM with a computer, use a cross- over cable. If you connect the SPM to a computer via a switch, this special cable type is not required. The IP address of the module in the delivery state is indicated on the name plate.
  • Seite 8: Technical Data

    12…24 V DC Fig. 3: Login with user name and password Only use a power pack with safe isolation for the power supply. You can configure the SPM in the following settings menu Power < 6 W (see Fig. 4). consumption Details can be found on the enclosed USB stick in the file “SPM_Accessing_Configuration”.
  • Seite 10 German language. R412026734-BAL-001-AB/2019-07 Subject to modifications. © All rights reserved by AVENTICS GmbH, even and especially in cases of proprietary rights applications. It may not be reproduced or given to third parties without its consent.
