C) POWER SUPPLY
Power supply symbol (number of phases and
frequency)
Assigned power supply voltage
Maximum power supply current
Maximum effective power supply current (identifies
the line fuse)
D) OTHER CHARACTERISTICS
Degree of protection .

INSTALLATION

INSTALLATION
WARNING: This Class A equipment is not
intended for use in residential locations where the
electrical power is provided by the public low-
voltage supply system. There may be potential
difficulties in ensuring electromagnetic compatibility
in those locations, due to conducted as well as
radiated disturbances. The MAX 223C Pipeline
equipment is NOT in compliance with IEC 61000-
3-12
In the event the equipment is connected to a
municiple low voltage
responsibility of the
technician, that they may want to consult first with
the local Municipality prior to connecting the
equipment. Correct installation is important for the
good operation and performance of the machine,
you must therefore proceed as follows:
- Position the machine in such a way that there is
no obstacle to the air circulation ensured by the
internal fan since the internal components require
suitable cooling.
- Ensure that the fan does not send deposits or
dust into the machine.
- Avoid impacts, rubbing, and – absolutely no
exposure to dripping water, excessive heat
sources, or any abnormal situations.
MAIN VOLTAGES
The machine operates from the following mains
supply voltage:
MAX 223C PIPELINE
e Fuse rating di
CONNECTION
- Before making the electrical connections between
the welding machine and the line switch, ensure
that the switch is turned off .
- The distribution panel must comply with the
regulations in force in the country of use.
- The mains system must be of the industrial type.
- For longer connecting cables, increase the lead
section as required.
- When using long extension cables, the cable core
diameter size is relevant
requirements for achieving optimum performance.-
- The power input supply socket from the mains
network, it is the
operator or electrical
400V 3P +/- 10%
16 A T Fuse
to the machine
voltage supply, must have a suitable switch
provided together with a 'slow-burning' type
fuse(s).
- In the event of damage to the power cable,
replacement or repair must be performed by a
qualified person at an approved service centre.
EARTHING
- To ensure user protection the welding machine
must absolutely be correctly connected to the earth
system (INTERNATIONAL
REGULATIONS).
- It is indispensable to provide good earthing by
means of the yellow-green lead in the power cable,
in order to avoid discharges due to accidental
contacts with earthed objects .
- The chassis (which is conductive) is electrically
connected with the earth lead; if the equipment is
not suitably connected to earth it may cause
electric shocks which are dangerous for the user.
INSTRUCTION FOR
INSECURE POSITIONING
Failure to properly secure the machine can cause
personal injury. If machine is in an insecure
position do not attempt to switch on. Do not put the
machine on an unlevelled surface greater than 10°.
