GOLIATH JUNIOR III
SPECIFICATIONS
Description: 2x10 + Tweeter Speaker Enclosure
Power Handling: 350 watts RMS
Impedance: 8 ohms or 4 ohms – depending upon which
8-ohm model
model puchased (8-ohm and 4-ohm models available)
Frequency Response & SPL: 105 dB SPL @ 1W1M
(–3 db @ 45 Hz and 12 kHz)
Speaker Complement: (2) 10" PAS Drivers, (1) Foster Horn
Porting: Front Slot Port
Dimensions: 23"W x 15.75"H x 16.5"D
Weight: 55 lbs.
4-ohm model
P.A.S. 10" SPEAKER SPECIFICATIONS
Free Air Resonance: 47Hz
Individual Impedance: 8 Ohms (each)
Power Rating: 175 Watts RMS (each)
CONNECTION AND OPERATION
The SWR Goliath Junior III can be connected to any musical instrument amplifier capable of driving a 4 or 8 ohm load. To con-
nect your amplifier to Goliath Junior III, run a high quality speaker cable (18 gauge or heavier) from your amplifier's speaker
output to one of the designated speaker inputs (Speakon or 1/4") on Goliath Junior III's input panel.
POWER HANDLING
The power output rating for any amplifier that is connected to Goliath Junior III should not exceed the enclosure's 350 watt
RMS power handling capacity. Please be aware that exceeding Goliath Junior III's power handling capacity can void the SWR
warranty if any damage occurs to your loudspeakers due to overpowering.
FULL RANGE INPUT AND OUTPUT JACKS
Goliath Junior III features four, full range input/output jacks (two standard 1/4" and two Speakon) wired in parallel. If you are
running two speaker enclosures in parallel, connect the speaker cable from your amplifier to either jack labeled "IN, " and a
second speaker cable from either jack labeled "OUT" to the input of the second speaker enclosure.
TWEETER ATTENUATOR CONTROL
The large dial found on the input panel of the cabinet is the Tweeter Attenuator. This control is used to adjust the level of high
frequency signal present at the tweeter. A normal setting for this control is straight up or "twelve o'clock." Turning the dial fully
counter-clockwise removes the tweeter from the circuit. As you turn the dial clockwise from this position, the high frequency
content is increased.
INTERNAL CROSSOVER
Goliath Junior III's internal (passive) crossover divides the incoming signal into two frequency bands. The crossover point is 5
kHz (frequencies above 5 kHz are sent to the tweeter, frequencies below 5 kHz are sent to the 10" speakers).
14 • Professional and Custom Pro Specialist Series
