Setting Up The Camera - switel SPF8266 Benutzerhandbuch

Setting up
1

Setting up the Camera

1
.1 Select Channels
1. Loosen the screw on the back of the camera by using a screwdriver.
2. Select the channel on the camera by sliding the slide switches on the front
of the camera. See Fig. 3.
(Slide the switches by using a screwdriver.)
1
.2 Positioning the Camera
1. Fix the camera to the wall or ceiling using the masonry plugs and fixing
screws supplied. See Fig. 4 and Fig.5 .
2. Select a suitable location to drill a cable entry hole.Depending on the
location, this can be through the house wall or through a door or
window frame.
1
.3 Power Supply
1. Connect the plug of the power adapter with the Power In socket
of the cable from the camera.
Make sure power plugs and pushed all the way in.
2. Plug the AC adapter into a wall outlet. See Fig.6 .
How to use the waterproof tape
After connecting the plug of the power adapter to the Power In socket
of the camera, use the provided waterproof tape to prevent moisture
and dirt getting inside.
1. Remove the release liner and wrap the waterproof tape in a
spiral around the plug and socket. Wrap the tape with enough tension
to obtain conformability on the surface.
2. Overlap by at least half the width of the tape so it bonds to itself,
while removing the release liner. See Fig 6.
1
.4 Fine Tuning
1. Adjust the camera's viewing angle according to the illustrations of Fig . 7
2. Loosen the screw on the back of the camera by using a screwdriver.
3. Rotate the camera to make adjustments.
4. When satisfied with the picture coverage, retighten the screw.
2
