1. UNLOADING

The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device secured with cardboard angle sections and foil.

2. PROPERTIES OF THE DEVICE

2.1. Purpose

Cabinets produced by the "Igloo" company are enumerated among professional cooling and freezing cabinets.
They are aimed for short-lasting storage of food products. These devices are used in gastronomy entities, confec-
tioneries, coffee houses and store chains. Storing food products in cooled condition enables to maintain its taste,
smell and aesthetic values. Guaranteed temperatures within the display cabinets: cooling cabinets +2ºC/+8ºC;
medium-freezing (SM) cabinets -6ºC/-2ºC and freezing cabinets (M) -18ºC/-12ºC with surrounding temperature
between +15ºC and +25ºC and relative air humidity of up to 60%.

2.2. Description of the device

The "AG" cabinets are equipped with internal aggregate, placed in the upper part of the device. Cooling occurs as a result
of forced air circulation. All cabinets are equipped with automatic defrosting and electronic thermostat optionally coopera-
ting with temperature recording module enabling to record and signal too low and too high temperature within the device.
Depending on option, they may be equipped with automatic condensate evaporation.
Depending on the type of the cabinet, they may be divided into full cabinets, and glass cabinets. Cabinets are equipped
with 5 rows of grid shelves with height regulation. Our devices are made according to modern technologies and have all
certifi cates required by law.
Contents
1. UNLOADING
2. PROPERTIES OF THE DEVICE
2.1. Purpose
2.2. Description of the device
2.3. Technical data
3. PREPARING THE DEVICE FOR EXPLOITATION
3.1. Requirements concerning the place of installation
3.2. Connection and actuation
4. EXPLOITATION
4.1. Temperature regulation
5. MAINTENANCE
5.1. Cleaning and maintenance
6. SERVICE
6.1. Fault identifi cation and repair
6.2. SERVICE
7. THERMOSTAT SERVICE
7.1. "IGLOO" thermostat
7.2. "CAREL" thermostat
This sign signifi es information of particular meaning for user security and for proper device
exploitation.
www.igloo.pl
COOLING CABINETS, MEDIUM-FREEZING AND FREEZING CABINETS WITH UPPER AGGREGATE ("AG" TYPE)
COOLING CABINETS, MEDIUM-FREEZING
WITH UPPER AGGREGATE ("AG" TYPE)
List of Figures
11 Fig.1 Construction of the device
11 Fig.2 Fixing the door grip
11 Fig.3 Mounting perforated shelves
11 Fig.4 Condensate tray
12 Fig.5 Control panel
13 Fig.6 Temperature sensor inside the cabinet
13 Fig.7 Cleaning the condenser
13 Fig.8 Changing the fl uorescent lamp
14 Fig.9 Data plate
15 Fig.10 „Igloo" thermostat panel
15 Fig.11 „Carel" thermostat panel
15
17
17
18
List of tables
19
19
20
Table 1 „EWA"* CABINET
Table 2 „JOLA"* CABINET
Table 3 „OLA"* CABINET
Table 4 „OLA 2" CABINET
AND FREEZING CABINETS
en
en
12
14
14
14
14
16
16
16
18
19
20
12
12
13
13
11
