Assembly Instruction; Folding Instructions - Milly Mally RIDER Gebrauchsanleitung

Please read this instruction sheet carefully and keep it for future
EN
reference. Not adhering to the rules mentioned below may put your
child at risk.

ASSEMBLY INSTRUCTION

INSTALLATION OF FRONT WHEELS
1) Put the front wheel set on the pram frame and secure with fastener in its
proper position.
OPENING THE PRAM
Before opening the pram, please make sure your children are in secure
distance from it. Make sure that the movable parts of the pram will not
reach the child and hurt child during handling.
2) Hold the pram in vertical position with wheels directed forward.
Before using the pram make sure that it is secured in opened position
with fasteners, especially check if the fastener on back of the pram is
properly done.
3) Release the lock (A) and push pram front (B) forward.
4) Press the mechanism on back locking the main fastener.
ADJUSTMENT OF BACKREST
5) Find the backrest adjustment mechanism installed on backrest back.
Press the pushbutton and adjust the position moving upwards or
downwards.
ADJUSTMENT OF FOOTREST
This operation may be made difficult by the weight of the pitting child.
The footrest enables assuring additional comfort to your child.
6) In order to adjust the footrest press to levers below the seat and move
the footrest.
REAR BRAKES
Before using the pram make sure that it is secured in opened position
with fasteners, especially check if the fastener on back of the pram is
properly done.
7) In order to block the brakes press both levers placed between the wheels.
8) To unblock the brakes – lift both levers placed between the wheels.
06
ROTATING WHEELS
The rotating wheels facilitate manoeuvres on even surfaces. For safety
reasons it is recommended to block the rotation of wheels (on gravel
roads or other unpaved surfaces). Remember, that always both wheels
must be blocked or unblocked at the same time.
9) In order to unblock the rotating wheels the lever placed between the
wheels shall be pulled upwards (A). It is recommended to use unblocked
rotating wheels on even surfaces. In order to block the rotating wheels
the same lever shall be pressed downwards (B).
BASKET AND SHELF FOR GOODS
Never put loads weighing more than 3 kg inside the basket.
10) The basket shall be secured using the straps to tight it to the frame as
specified on the attached drawing.
HOOD
The hood must be attached to the pram on both sides. Please make sure
that the hood is secured in its proper position. PRAM TOPPLING
PREVENTION: never overload the pocket of the hood. Maximum
allowable load is 0.45 kg.
11) In order to install the hood on the pram slip the plastic bolts inside the
guides of the pram frame.
12) Open the hood (A) and secure its position by pressing two blocking
mechanisms on the sides (B).

FOLDING INSTRUCTIONS

HOOD
13) In order to fold the hood pull two blocking mechanisms on hood sides (A)
and pull the front part of the hood towards yourself (B).
FOLDING THE PRAM
Before using the pram make sure that it is secured in opened position
with fasteners, especially check if the fastener on back of the pram is
properly done.
14) Before folding and closing the pram, fold the hood according to item 13.
Then pull the main mechanism of the rear blocking up using the hand
