REQUIRED FOR OPERATION (Purchase separately)
# C4995
MASTER Digital Servo DS3012 oder/or
# C5638
MASTER Digital Servo DS3012 MG
(Purchase separately)
GLUE
SILICON
X1075 Silex Silicon
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Sander
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Masking tape - Straight Edged Ruler - Pen or pencil - Drill and Assorted Drill Bits
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
Symbols used throughout this instruction manual, comprise:
Drill holes using the stated
size of drill
1.5mm
(in this case 1.5 mm )
A B
Use epoxy glue
Read through the manual before you begin, so you will have an overall idea of what to do.
CONVERSION TABLE
3.0mm = 1/8"
1.0mm = 3/64"
4.0mm = 5/32"
1.5mm = 1/16"
5.0mm = 13/64"
2.0mm = 5/64"
6.0mm = 15/64"
2.5mm = 3/32"
# C5753
Propeller P-CON 12x6
# C6741 LiPo LEMONRC 3700-11,1V
# X3572 Zoom Sekundenkleber
(Purchase separately)
Phillip screw driver
Scissors
!
T ake particular care here
Apply cyano glue
CA
10mm = 13/32"
12mm = 15/32"
15mm = 19/32"
20mm = 51/64"
CA Glue
Hatched-in areas:
remove covering
film carefully
Assemble left and right
L/R
sides the same way.
25mm = 1"
30mm = 1-3/16"
45mm = 1-51/64"
# C2036
Servo Verlängerungskabel 400mm
Servo Extension Cord 400mm
# C2983
Brushless Combo BOOST 40
inkl. Motor, Regler, Programmkarte
including motor, ESC and program card
X3598-120 Epoxy
EPOXY A
5-Min.
EPOXY B
Hex Wrench
Awl
Wire Cutters
Check during assembly that these
parts move freely, without binding
Not included.
These parts must be
X
purchased separately
Low seting
