Datasheet_CIS_ENG
Final Version
CIS
Industrial Solar Charge Controller
TYPE
Nominal voltage
Max. Charge / Load Current
Float Voltage
Boost Voltage
Boost Cycle Activation
Equalization Voltage
Equalization Cycle Activation
Additional Equalization
Load Disconnect Voltage
Load Reconnect Voltage
High Voltage Disconnect
Emergency Switch Off
Max. Solar Voltage
Temperature Compensation
Max. Self Consumption
Ambient Temperature range
Max Altitude
Battery Type
Evening/Morning Hours range
Night/Day Detect range
Dimensions
Weight
Wire size
Type of protection
Dim Output Specifications
Dimming Value
Dimming Terminal Output Voltage
Dimming Terminal Output Current
20090914
Subject to change without notice
CIS XX
12 V/24 V automatic recognition
5 A , 10 A , 20 A
o
13,8/27,6 V (25 C)
o
14,4/28,8 V (25 C), 2h
If battery voltage goes below
12.3 V / 24.6 V
o
14,8/29,6 V (25 C), 2h
If battery voltage goes below
12.1 V / 24.2 V
Every 30 days
11,00 - 12,02 V/22,00 - 24,04 V
12,8V / 25,6 V
15,5 V / 31,0 V
< 10,5V / 21 V
55 V, by varistor
-4,2 mV/K per cell
5 mA - 8 mA / 6 mA - 10 mA
o o
-40 C to + 60 C
4000 m
Sealed, Flooded
0 - 15 Hours / 0 - 14 Hours
2,5 - 10 V
82 mm X 58 mm X 20 mm
150 gr.
1.5 mm 2 for 5 A/10 A
2
2.5 mm for 20 A
IP68 (1,5 m, 72 h)
0 -- 100% output power
0 - 5 V
< 1 mA
CIS XX 2L
12 V/24 V automatic recognition
5 A , 10 A , 20 A
o
13,8/27,6 V (25 C)
o
14,4/28,8 V (25 C), 2h
If battery voltage goes below
12.3 V / 24.6 V
o
14,8/29,6 V (25 C), 2h
If battery voltage goes below
12.1 V / 24.2 V
Every 30 days
11,00 - 12,02 V/22,00 - 24,04 V
12,8V / 25,6 V
15,5 V / 31,0 V
< 10,5V / 21 V
55 V, by varistor
-4,2 mV/K per cell
5 mA - 8 mA / 6 mA - 10 mA
o o
-40 C to + 60 C
4000 m
Sealed, Flooded
0 - 15 Hours / 0 - 14 Hours
2,5 - 10 V
82 mm X 58 mm X 20 mm
150 gr.
1.5 mm 2 for 5 A/10 A
2
2.5 mm for 20 A
IP68 (1,5 m, 72 h)
N/A
N/A
N/A
