Netzteil 1-fach Art.Nr. 117 899 min 12 cm 20° Netzteil 5-fach Art.Nr. 113 792 Netzteil 230 V / 12 V nicht in Rohbauset oder eventuellen Schutzbereichen anbringen. Steuerleitung für Variante mit TD: 2 x 0,5 mm max. 100 m Gesamt-Kabellänge SanTec PROOF W6 Wandarmatur...
Seite 4
Zeit-Regler Anschluss Ansteuerung zum Öffnen der 38 °C für thermische Desinfektion Intervall-Regler Sicherheitssperre. Anschluss Infrarot-Sensor Dip-Schalter zum Einstellen Infrarot-Sensor für die der Funktionen Anschlussklemme für 12 V Benutzererkennung Anschluss Bypass-Magnet- Spannungsversorgung (Ansprechbereich). ventil f. therm. Desinfektion SanTec PROOF W6 Wandarmatur...
Seite 12 Funktions-Aktivierung - Dip-Schalter 3 - 6: Dip-Schalter Funktion Beschreibung Reinigungsstopp Seite 13 Dauerlauf Seite 14 Stagnationsfreispülung Seite 15 Nachlaufzeit ON = 5 s / OFF = 2 s Programm oder Funktionen bereits werksseitig voreingestellt. SanTec PROOF W6 Wandarmatur...
Vorstehenden Teil des Rohbaukastens fliesenbündig Folgende Schritte unbe- abschneiden. dingt in beschriebener Reihenfolge ausführen! Ggf. zwischen Wand und Rohbauset mit Silikon abdichten. Wasserzuleitung absperren. 5. Beide Vorabsperrungen mit einem Schraubendreher öffnen Adapter für Thermostat mit Inbus 2,5 montieren. SanTec PROOF W6 Wandarmatur...
Seite 8
Elektro-Anschluss am Elektronikmodul herstellen. +/- Polung beachten. Anschließend Spannungsversorgung einschalten. (Sicherheitsschließimpuls vom Magnetventil erfolgt.) Montagerahmen mit 4 Schrauben befestigen. Dabei auf die Kabelverbindungen achten und die Kabel nicht quetschen. Beim Anziehen der Schrauben darauf achten, dass sich der Montagerahmen nicht verformt. SanTec PROOF W6 Wandarmatur...
Seite 9
Gewünschte Funktions-Einstellungen am Elektronikmodul vornehmen und Elektronik in das Rohbauset geben. Thermostatposition kontrollieren - Pfeil zeigt nach oben. Position des Thermostatknopfes kontrollieren - Absperrknopf zeigt senkrecht nach oben. Frontplatte schräg aufsetzen und mit Druck in die waagrechte Position drehen. SanTec PROOF W6 Wandarmatur...
Seite 10
PROOF W6 Montage Kunststoff-Distanzring über das Auslaufrohr zur Frontplatte führen. Frontplatte mit Sicherungsschraube rechts unten sichern. Designauslauf über Auslaufrohr schieben, ausrichten und von unten mit Wurmschraube befestigen. Hauptwasserleitung öffnen. Funktionstest durchführen. SanTec PROOF W6 Wandarmatur...
Bei Durchlaufthermen kann die verlängerte Nachlaufzeit eingestellt werden, um die Anzahl der Zündvorgänge zu minimieren. Dip Schalter 6 ON = Verlängerte Nachlaufzeit - 5 s Dip Schalter 6 OFF = Standard Nachlaufzeit - 2 s (voreingestellt). SanTec PROOF W6 Wandarmatur...
Seite 12
(unterhalb des Thermostat- 3 4 5 6 stopp-Zeit. Zum Vorzeitigen griffs) startet der Wasserfluss Aufheben des Wasserflusses automatisch. halten Sie die Hand nahe vor den Infrarot-Sensor bis der Wasserfluss stoppt. (Zeit-Regler 10 bis 60 s einstellbar) SanTec PROOF W6 Wandarmatur...
Wasserfluss startet und wie- 3 4 5 6 ersten 3 s nach Aus- der stoppt. Zur vorzeitigen Beendigung lösung des Wasser- des Reinigungsstopps gehen flusses aktiviert Sie gleich vor wie bei der werden. Aktivierung. SanTec PROOF W6 Wandarmatur...
Seite 14
3 s verweilen. (unterhalb des Thermostat- griffs) und warten, bis der Nach Verlassen des Ansprech- Wasserfluss startet, dann bereichs geht die Armatur stoppt und danach wieder wieder in den Normalbetrieb startet. Dann ist der Dauerlauf über. aktiviert. SanTec PROOF W6 Wandarmatur...
Seite 15
Stagnations- eingestellte Zeit nicht be- freispülung erst 2 min nach nützt, löst die Armatur eine Beendigung des Reinigungs- automatische Stagnations- stopps aus. freispülung für 10 s aus. 3 - 48 h 10 s SanTec PROOF W6 Wandarmatur...
This manual is valid for the following products: SanTec PROOF W6 wall tap control: Art.Nr. 118 728, 118 735, 118 766, 118 773 SanTec PROOF W6 wall tap control with thermal disinfection: Art.Nr. 118 742, 118 759, 118 780, 118 797 Delivery scope:...
Seite 19
PROOF W6 Specifi cations Operating voltage: via power supply 230 V 50 Hz / 12 V= Art.No. 117 899 - power supply for one control unit Art.No. 113 792 - power supply for up to 5 control units Power consumption: max.
Seite 20
PROOF W6 Dimensions All dimensions in mm: 20° 185/240 Legend Front plate: Electronics module controls: 1 2 3 4 5 6 1 2 3 4 5 6 Thermostat knob to adjust Time control Connection, control line for the temperature, including a Interval control thermal disinfection button for bypassing the 38...
+ – 3 4 5 3 4 5 3 4 5 3 4 5 Wiring diagram: SanTec PROOF W6 Control line for thermal disinfection 2 x 0.5 mm total cable length max. 100 m Key switch (without cylinder) Art. no. 110 418...
Seite 22
PROOF W6 Configuring the programs & functions Regulator controls: Range control Time control Interval control User detection range preset for safety flow arrest for stagnation rinse, default to 30 cm (configurable from preset to 1 min setting 48 h (setting range 15–30 cm).
Seite 23
PROOF W6 Assembly Remove the flush-mount protective cover. ATTENTION! Cut off protruding parts from the flush-mount box so it aligns Perform the following steps with the tiles. in the order indicated! Where necessary, seal off space between wall and flush- mount set with silicone.
Seite 24
PROOF W6 Assembly Remove the sealing plug and mount the outlet pipe. 8. Feed the power connection cable (2 x 0.5 mm ) and, if applicable, the control line for thermal disinfection (2 x 0.5 mm ) into the flush-mount set and connect it/them to the power supply (art.
Seite 25
PROOF W6 Assembly Correctly align the mounting frame. Apply the included special grease to the front of the valve. ATTENTION! Perform the following steps Connect the mounting frame sensor cable to the electronics in the order indicated! module. Configure the desired functions at the electronics module, and insert the module into the flush-mount kit.
Seite 26
PROOF W6 Assembly Place the plastic spacer ring over the outlet pipe towards the front plate. Arrest front plate by fastening the locking screw at the lower right. Place the design spout over the outlet pipe, and arrest it at the bottom using the Allen screw.
PROOF W6 Werkseinstellung: Program description 1 2 3 4 5 6 Fully automatic program mode (default setting): DIP switch 1=ON, 2=ON 2 3 4 5 6 2 3 4 5 6 Switch off Switch on Safety flow arrest Once you clear the sensor As soon as you enter the After the configured water range or after the configu-...
Seite 28
Werkseinstellung: PROOF W6 1 2 3 4 5 6 Program description 2 3 4 5 6 Auto shutdown program mode: DIP switch 1=OFF, 2=OFF 2 3 4 5 6 3 4 5 6 Switch off Switch on The water will automati- Approach the infrared sensor cally stop flowing after the (below the thermostat knob)
Seite 29
PROOF W6 Program description Werkseinstellung: Cleaning stop: DIP switch 3 4 5 6 1 2 3 4 5 6 Serves to disable automatic activation prior to cleaning. 1 2 3 2 3 4 5 6 DIP switch 3 ON = Cleaning stop function enabled (default setting). DIP switch 3 OFF = Cleaning stop function disabled.
Seite 30
PROOF W6 Werkseinstellung: Program description 4 5 6 1 2 3 4 5 6 Continuous flow: DIP switch 4 1 2 3 2 3 4 5 6 Enable the continuous flow function to fill the washbasin or a container. 2 3 4 5 6 1 2 3 4 DIP switch 4 ON = Continuous flow function enabled.
Seite 31
Werkseinstellung: PROOF W6 4 5 6 1 2 3 4 5 6 Program description 1 2 3 2 3 4 5 6 Stagnation rinse: DIP switch 5 1 2 3 4 2 3 4 5 6 Serves to rinse water supply lines in order to remove stagnant water 3 4 5 6 1 2 3 4 5 that accumulates during longer periods of disuse.
