SETTING HSIC
In the submenu NETWORK the network settings of the fixture can be set.
NET SWITCH: activates (ON) or deactivates (OFF) the integrated ArtNet node.
IP MODE: submenu for setting the ip-address. Users can choose between DEFAULT IP or
CUSTOM IP. If set to CUSTOM IP the users needs to set a custom ip in the next step.
CUSTOM IP EDIT: in this menu a user defined ip-address can be set.
UNIVERS: the universe of the ArtNet node is set.
Activate Password Protection
MENU
HSIC KEY
In the menu KEY the password protection of the fixture is activated or deactivated. If set ON the
fixture is password protected when started. 30 seconds after the last setting the menu is locked
again. To be able to make changes in the menu the password UP - DOWN - UP - DOWN - ENTER
needs to be typed in.
Calibration and Whiteadjustment
MENU
CALIB.CCT HSIC
In the menu SETTING\CALIB.CCT the colour temperatures for the white values are stored.
In the submenu WT the colour temperatures for the white values are stored. These are mixed from
the parameters RED, GREEN, BLUE, and WHITE.
To reset the changes made to the colour temperature presets to factory default, the setting
CALIB.RESET needs to be confirmed with the default password UP - DOWN - UP - DOWN -
ENTER
In the menu RGBtoW a custom colour calibration is stored which limits the maximum brightness of
the colour channels RED, GREEN, BLUE at the DMX value "255".
NOTE: The maximum value can be limited to 0. In this case, a colour channel does not respond
to a sent DMX value, which can be misinterpreted as a device error.
NETWORK
****
ON
OFF
WT
****
CALIB.RESET
RGBtoW
E-30
NET SWITCH OFF
ON
IP MODE DEFAULT IP
CUSTOM IP
CUSTOM IP SET XX.XX.XX.XX
UNIVERS XXX
2700K RED
3000K
GREEN
o
BLUE
o
WHITE
o
10000K
****
R.(0-255)
RED
G.(0-255)
GREEN
BLUE B.(0-255)
R.(0-255)
G.(0-255)
B.(0-255)
W.(0-255)
