Introduction

PhotoBank is an innovative handheld device that allows you to store and
manage your photo files from your digital camera. PhotoBank includes a
built-in battery, memory card reader slots, a high capacity hard drive,
status display, and a Hi-Speed USB interface. Once your unit is
connected properly to your computer running a recent operating system,
you will also be able to use it as you would any external hard drive for
performing data storage functions.
Before you begin to use PhotoBank for the first time, there are a few
important things to learn about your new product.

Controls, Connectors and Indicators

First familiarize yourself with the display, control keys, and the various
connectors on the unit.

Top Surface - Display

Along the top surface you will find the status display. The display shows
you the current status while the unit is powered on. See the figure below
for a description of the icons and information provided by the display.
