Mit der Wahl für ein VC Produkt haben Sie sich für
das höchste Qualität und Zuverlässigkeit gewährleistet.
Bitte lesen Sie die nachfolgenden Hinweise vor
der Installation bzw. Inbetriebnahme genau durch, damit Sie
in den vollen Genuß aller Produktvorteile kommen.
IP-Kameras der R-Serie
Änderungen in Technik, Design und Ausstattung vorbehalten
Installations- und Betriebsanleitung
Installations- und Betriebsanleitung
Sehr geehrter Kunde!
ein professionelles Gerät entschieden,
Art. Nr. 12071
Art. Nr. 12071-B
Art. Nr. 12071-4B
Art. Nr. 12071-4M
Art. Nr. 12072
Art. Nr. 12073
Art. Nr. 12073-B
Art. Nr. 16827
Art. Nr. 16829
Art. Nr. 16831
Art. Nr. 16842
VC Videocomponents GmbH, Brachenfelder Str.45, 24534 Neumünster
Änderungen in Technik, Design und Ausstattung vorbehalten
©
IB_12071 / 24.05.2016
Werbung
Inhaltsverzeichnis
Verwandte Anleitungen für VC R-Serie
Inhaltszusammenfassung für VC R-Serie
- Seite 1 Installations- und Betriebsanleitung Installations- und Betriebsanleitung Sehr geehrter Kunde! Mit der Wahl für ein VC Produkt haben Sie sich für ein professionelles Gerät entschieden, das höchste Qualität und Zuverlässigkeit gewährleistet. Bitte lesen Sie die nachfolgenden Hinweise vor der Installation bzw. Inbetriebnahme genau durch, damit Sie in den vollen Genuß...
-
Seite 3: Sicherheitshinweise
Installations- und Betriebsanleitung Sicherheitshinweise Lesen Sie diese Installations-und Betriebsanleitung vor Inbetriebnahme sorgfältig durch! Damit werden eventuelle Schäden durch nicht sachgemäßen Gebrauch vermieden. Beachten Sie die am Gerät angebrachten Warnhinweise. Die Geräte dürfen nur in nicht explosionsgefährdeten Bereichen eingesetzt werden. Bevor Sie das Netzteil anschließen, achten Sie darauf, dass die Spannung und Stromaufnahme vom Netzteil der Spannungsangabe des Gerätes entsprechen. -
Seite 5: Inhaltsverzeichnis
Contents Overview..............................1 Safety Instructions............................2 Application Fields............................3 Product Features............................3 Device Installation and Connection......................4 Appearance Description..........................4 Device Connection............................7 Device Search Tool............................8 ActiveX Control Setup..........................12 Webpage Configuration of IP Camera......................13 Live................................13 Parameter Setting............................15 Display..............................15 Network..............................18 Alarm................................ 26 Device............................... -
Seite 6: Overview
USER MANUAL Overview Thank you for using our IP camera product series, which are integrative products developed for the network video surveillance. On the basis of the newest solutions of Hisilicon, the product series develop a media processing platform by integrating the capture, compression and network transmission of audio and video on one board.With standard H.264 encoding algorithm, the products ensure clearer and smoother video transmission. -
Seite 7: Safety Instructions
USER MANUAL Safety Instructions To correctly use the product and avoid danger or property loss, please carefully read this manual before operation and keep properly for later reference. Use suitable power supply (attached or specified by the manufacturer). Do not use unspecified power supply. -
Seite 8: Application Fields
USER MANUAL Application Fields IP camera is usually applied in large-scale shopping malls, supermarkets, schools, plants, workshops, and other public places. As it has strong image processing capacity, IP camera can also be used in the environment requiring high definition of image, such as bank and traffic intersection. Refer to the following picture. -
Seite 9: Device Installation And Connection
USER MANUAL Device Installation and Connection Appearance Description Schematic Diagram（Art.Nr. 12071) Items Descriptions ① Front cover It can prevent the IP camera from the irradiation of the sunlight. ② Rear cover It is fixed with the front cover. ③Focusing lever Adjust the focal length of the camera. - Seite 10 USER MANUAL Schematic Diagram（Art.Nr. 12073） ② ③ ① ④ ⑤ Items Descriptions ① Transparent cover Protect the hemisphere ② Infrared lamp Infrared LED lamp ③ Lens Lens of camera ④ Black inner cover Fix the hemisphere ⑤ Adapter disc Connect tailing line and fix adjustment bracket...
- Seite 11 USER MANUAL Schematic Diagram（Art.Nr. 12072） ① ② ③ ④ ⑤ ⑥ Items Descriptions ① Lens Lens of camera ② Infrared lamp Infrared LED lamp ③ Hemisphere It is rotatable and used to adjust the installation angle ④ Fixed guard Fix the position of the hemisphere. ⑤...
-
Seite 12: Device Connection
USER MANUAL Device Connection There are two types of connection： 1. Connect the device with PC Connect IP camera with PC by network cable. The supply hub of IP camera is connected with DC 12V power supply. Set the IP of PC and that of IP camera in the same network segment. If the network is normal, wait for 1 minute after power on and IP camera will establish communictaion with PC. -
Seite 13: Device Search Tool
USER MANUAL Device Search Tool The software can detect the IP address of IP camera in the LAN. Firstly, install .exe file (Device Search) in the included CD by the following procedures.： Double click the .exe file Click [Next] to continue. 3. - Seite 14 USER MANUAL 4. Click [Install] to begin the installation.
- Seite 15 USER MANUAL 5. Click [Finish] to finish the installation. Run the installed Device Search.exe software. Click to run the software and it will automatically display the IP address, subnet mask, gateway, port, version information and MAC address of the running IP camera in the current LAN, as shown in the following picture：...
- Seite 16 USER MANUAL If the searched IP address and PC IP address are not in the same network segment, user may modify IP address, subnet mask, port number and other parameters of IP camera by using Device Search software. In the DeviceSearch software, select a device to modify IP address and then input new IP address, subnet mask, gateway, port number and administrator password(default: admin).
-
Seite 17: Activex Control Setup
USER MANUAL ActiveX Control Setup If the user visits IP camera with Internet Explorer for the first time, he has to install the plug-ins. For installing the plug-ins, it is necessary to set the browser security level. Enter menu [Tools/Internet Options/Security/Custom Level] and change “ActiveX controls and plug-ins” as “Enable”... -
Seite 18: Webpage Configuration Of Ip Camera
USER MANUAL Webpage Configuration of IP Camera Live Open Internet Explorer and input IP address of IP camera （http://192．168．1．168）. The login dialog box will appear. See the following picture： User may select stream types and fluent level in the login interface. Input user name(default: admin) and password (default: admin) and click “Login”... - Seite 19 USER MANUAL Other buttons on the Live interface： ：Enter the device setting menu and set customized parameters of the device； ：Snapshot, file ty pe, storage path, etc.； ：Log out and return to the login interface； ： It shows preview control buttons. From the left to the right, the names of buttons are play, stop, full screen, snapshot, start/stop recording, enable/disable talkback.
-
Seite 20: Parameter Setting
USER MANUAL Parameter Setting Display Live Click ，and enter the following interface（Live interface by default）： Channel Name:Name of IP camera Channel Display:Enable or disable. It may customize the display location. Time Display：Enable or disable. It may customize the display location. Flicker Control ：50HZ, 60HZ or disable Transparency：Set the transparency of OSD background color. -
Seite 21: Image Control
USER MANUAL Image Control Click【Display】→【Image Control】to enter the following interface.： IRCUT Mode：4 modes: GPIO Auto, Video Auto, Color Mode and Black & White Mode. IR-CUT Delay：Set IRcut delay switching time Image flip：Lens flip and angle flip Back light：Enable or disable the Back light. When enabled, there are three levels: low, middle and high. -
Seite 22: Privacy Zone
USER MANUAL AGC：Adjust the level of AGC(low, middle and high) White Balance：Auto, manual and indoor Auto﹕Optimize according to the current lighting conditions and screen mode and calibrate the video color of the camera. Manual﹕Manually adjust red and blue gain of camera video Indoor﹕Optimize according to the indoor environment and automatically calibrate the video color of camera. -
Seite 23: Network
USER MANUAL Network Network Setting Click【Network】→ 【Network Setting】to enter the following interface： Type：DHCP or Static. Default type is Static. Client Port：Client port of IPC Web Port：Web port of IPC Mobile Port：Connection port of mobile client IP address：IP address of IPC Subnet Mask: Subnet mask of IPC Gateway：Default gateway of device DNS1/DNS2：Configure DNS server... -
Seite 24: Video Streaming
USER MANUAL Video Streaming Click【Network】→【Video Streaming】 to enter the following interface： Type：Main stream, sub stream and mobile stream User may set resolution, FPS, I Frame Interval, Rate control(CBR/VB R) and Bitrate Mainstream/Substream/Mobilestream. Resolution ：mainstream（1280×720）, substream（640×480）, mobilestream（320×240） FPS：When flicker control is 50HZ，it can be set as 25 at maximum; When flicker control is 60HZ， it can be set as 30 at maximum. - Seite 25 USER MANUAL Email Click【Network】→【Email】 to enter the following interface： ：Email service setting. Apply this function with alarm function and the images captured during alarming can be uploaded to E-mail server through network. SMTP Port ： Default value is 25 （ E-mail service Enable Email: Disable or enable port）...
- Seite 26 USER MANUAL DDNS Click【Network】→【DDNS】 to enter the following interface： ： It refers to Dynamic Domain Name Server, which is used together with server for outer network accessing. DDNS：Enable Server ：Select 3322 Host Name：Input the host name User Name：User’s name Password：User’s password...
- Seite 27 USER MANUAL IP Filter Click【Network】→【IP Filter】to enter the following interface： ：Three modes: allow all IP connection, allow all set IP connection, and disable set IP connection. ：Add allowed IP or disabled IP ：Delete added IP...
- Seite 28 USER MANUAL RTSP Click【Network】→【RTSP】to enter the following interface： RTSP:Enable or disable. Default setting is “Enable”. If it is set as “Disable”, user may not find through ONVIF. RTSP Port: Default value is 554. The value can be changed in the range of 1024-65535. After modification, the device will be restarted.
- Seite 29 USER MANUAL Click【Network】→【FTP】to enter the following interface： ：FTP service setting. This function is applied together with alarming function. The captured images or alarming recording can be uploaded to FTP server through network. FTP: Enable or disable User Name：User name for visitingFTP assword：Password for visiting FTP FTP Server：Input FTP server address Port：FTP service port，default value is 21...
- Seite 30 USER MANUAL GB28181 Click【Network】→【GB28181】to enter the following interface： The device supports GB28181 protocol. Click the option “Open and Effective” to enable the function. Set related registration information and click Save...
-
Seite 31: Alarm
USER MANUAL Alarm Motion Click【Alarm】→【Motion】to enter the following interface ： Setting procedure： 1. Click to enable motion detection. 2. Click and drag left mouse button to select motion detection area. 3. Set motion detection sensitivity(Range:1-8. Larger number indicates higher sensitivity.) 4. - Seite 32 USER MANUAL Block Alarm Click【Alarm】→【Block Alarm】to enter the following interface： Alarm for blocking of camera lens It can link SMTP to send by Email.
-
Seite 33: Device
USER MANUAL Device It contains【Log】and【Audio 】. Their interfaces and descriptions are as follows. Click【Device】→【Log】to enter the following interface： Log Type ：（ system log, parameter log, alarm log, storage log, all log ） , totally 5 types for selection. Set the begin time and end time of the searched log. Click “Search”... -
Seite 34: System
USER MANUAL Audio Click【Device】→【Audio】to enter the following interface： IPC audio switch Audio setting procedure ： Click “Enable Audio” and audio setting options appears. User may set the input volume and output volume in the range of 0-10. After setting, click Save to save the changed parameters. System System includes【Date/Time】,【Users】and【Info】. -
Seite 35: Date/Time
USER MANUAL Date/Time Click【Sy stem】→【Date/Time】to enter the following interface： In this interface, user may set Date/Time, including System Time, Date Format and Time Format. After setting, click Save. The device also provides three kinds of automatic time synchronization： DST ：Click DST to enable DST function. The device will synchronize time according to the time offset. - Seite 36 USER MANUAL NTP ：Synchronize time with NTP server. Click NTP to enable NTP setting. Input NTP server address, select time zone and click Save. The system will automatically synchronize time with NTP server. Synchronize with computer time ： Device will take computer as the time server to synchronize time.
-
Seite 37: Advanced
USER MANUAL Info Click【Sy stem】→【Info】to enter the following interface： It includes system information of the device, such as Device Type, MAC Address, Software Version, etc. Advanced It includes【Firmware Update】,【Load Default】and【Maintain】, as shown in the following picture. -
Seite 38: Firmware Update
USER MANUAL Firmware Update Click【Advanced】→【Firmware Update】to enter the following interface： In “Firmware Update” option, user may click “Scan ” to select update file, click Upgrade button and the system will be upgraded automatically. If the upgrade file does not match the device, the update will fail. -
Seite 39: Load Default
USER MANUAL Load Default Click【Advanced】→【Load Default】to enter the following interface： In “Load Default” option, click the corresponding options and click Save to restore factory settings for the selected options. - Seite 40 USER MANUAL Maintain Click【Advanced】→【Maintain】to enter the following interface： In “Maintain” interface, user may set periodically reboot or manual reboot.
-
Seite 41: Technical Parameters
USER MANUAL Technical Parameters Descriptions Items 100W 130w 200w Image Sensor CMOS Sensor Video Format P/N adaptive control 0.08Lux @(F1.2,AGC ON) , Camera Minimum luminance 0.03Lux @(F1.2,AGC ON) ,0 Lux with IR 0 Lux with IR Shutter speed 1/25s ~ 1/20,000s Day/night switch mode IR auto switch Video compression standard... -
Seite 42: Appendix 1Router Port Forwarding
USER MANUAL Appendix 1Router Port Forwarding If user wants to remotely visit IP Camera monitoring image through internet, he has to open web port and client port of IP Camera. Take Cisco router as an example： IP address of IPC is 192.168.1.168, web port is 8000 and client port is 9988.。... -
Seite 43: Appendix 2Faq
USER MANUAL Appendix 2FAQ ◆ IE cannot load and install plug-ins. Possible cause：IE security level is set too high. Solution：Set IE security level to the minimum level. ◆ After updating, user cannot visit IP Camera through IE. Solution ：Clear IE cache. Specific steps: Open IE Tools, open Internet option, click “delete file” button in the 2 option (temporary Internet files), click “delete all offline contents”, and click OK. -
Seite 44: Ihr Zuständiger Service-Händler
Installations- und Betriebsanleitung Ihr zuständiger Service-Händler Alle Rechte vorbehalten, auch die des Nachdrucks im Auszug, der fotomechanischen Wiedergabe und der Übersetzung. Änderungen in Technik, Design und Ausstattung vorbehalten...
