Tightening torque
Hexagon nut (64)
Fiat head screw (78)
Cheese head screw (66)
Hexagon screw (73)
Cheese head screw (98)
Hexagon nut (82)
Hexagon screw (88)
6.5 Assembly of complete motor
- Instructions on p. 6.2 are carried out in the reverse order Pay attention when positioning the
disk spring (31), (see example drawing). After mounting the armature (5) install 2 x cover (17)
and carbon brushes (15).
Printed in Federal Republic of Germany 12.2001
= 50.0 Nm
= 3.0 Nm
=1.5 Nm
= 3.0 Nm
= 4.5 Nm
= 6.5 Nm
= 6.5 Nm
Maybachstrasse 2
D-75433 Maulbronn • Deutschland
Telefon 07043/102-81/82 • Fax 07043/10278
- 12 -
Änderungen vorbehalten
Copyright by EFA
