Froggit WS80 Benutzerhandbuch Seite 9

Benutzerhandbuch Froggit WS80 Funk-Saunathermometer
IV Function and effect
run back by 8 steps/second
11. The system will exit automatically if no key is operated in 8 seconds
4.1 The receiving function of RF
1. After installing the battery and checking temperature, it will enter RF receiving state automatically
for 3 minutes
2. Under normal display mode, hold CH for 2 seconds to clear out the channel information
3. If there is no effective signal with same ID code received for the current channel in 60 minutes,
the temperature of that CH will show "_ _"
4. The temperature display will resume back when the correct signal is received again
5. RF receiving cycle: CH1= 57S, CH2=67S; CH3=79S
6. Sauna receiving cycle: 53S
4.2 Outdoor transmitter operation
1. After installing the batteries and checking temperature, it will display temperature data. And it will
transfer temperature data to main unit automatically
2. Press CH to switch the channel. Press °C/°F button to switch between temperature unit °C and °F
3. When temperature under -20 °C, put the wire probe to outside and keep transmitter inside the
house.
4. The measuring temperature range: -50 °C to +70 °C
4.3 Sauna transmitter operation
1. The use of sauna transmitter: put the wire probe metal part inside the sauna room and sauna
transmitter main unit outside.
2. After installing the batteries and checking, it will display temperature data. And it will transfer
temperature data to main unit automatically
3. Press TX button to force it to send signal, you will
the signal from Sauna transmitter, it will sound BI
4. The measuring temperature range: -10 °C to +140 °C.
4.4 The function of alarm
1. The BUZZER will ring for 2 minutes as below:
a. 0-10 sec: one " BI "per second
b. 10-20sec: two "BI" per second
c. 20-30sec: four "BI" per second
d. After 30 sec: "BI" continuously
2. When ringing, click SNOOZE once to enter into 5 minutes snooze states, exit if any other key is
clicked
see flash. When main unit receive
9
