ML.book Page 15 Wednesday, March 14, 2018 10:28 AM
60
Upper limit of external
static pressure (45Pa)
50
Lower limit of external
40
static pressure (45Pa)
30
Low (45Pa)
Low (35Pa)
20
Low (20Pa)
10
Low (10Pa)
0
500 600 700
60
Upper limit of external
static pressure (45Pa)
50
Lower limit of external
40
static pressure (45Pa)
30
Low (45Pa)
20 Low (35Pa)
Low (20Pa)
10
Low (10Pa)
0
500 600 700
EN-29
22 type
3
Standard Air Volume = 1000m /h
High (45Pa)
High (35Pa)
High (20Pa)
High (10Pa)
800 900 1000 1100 1200
3
Air Volume (m /h)
24 type
3
Standard Air Volume = 1060m /h
High (45Pa)
High (35Pa)
High (20Pa)
High (10Pa)
800 900 1000 1100 1200
3
Air Volume (m /h)
– 15 –
Connecting method of the duct
Connect a duct to the
outside of the flange. In
addition, the duct must be
covered with insulation
Duct: Insulation material
material so that the flange
(locally procured)
will not be exposed
Flange
Air discharge side
Attach the air intake grille and the air filter (locally procured) to the air intake side of ceiling opening
CAUTION
Incomplete heat insulation of the supply air flange and sealing may
occur dewing resulted in falling of water drop.
Installation Manual
Flange (locally procured)
Aluminum tape (locally procured)
Indoor unit
Air intake side
Aluminum tape (locally procured)
Under surface
EN-30
