SanDisk ImageMate Dual Schnellstartanleitung Zur Installation Seite 5

Figure 1.2 (SDDR-75 shown)
• LED power and activity lights. FIGURE 1.3
5) Power LED (amber color)
ON when the computer is on and reader is plugged into the USB port.
OFF when the computer is OFF or operating in suspend, hibernate or low power mode or reader is unplugged from
USB port.
6) Media LED 1 for SLOT 1
7) Media LED 2 for SLOT 2
ON when media is inserted properly.
ACTIVE (flash, blink) when there is activity (writing data) to or (reading data, downloading) from the memory card/ImageMate.
OFF when media is not inserted.
NEVER remove the media when the LED is ACTIVE, FLASHING, BLINKING.
Icons and removing your media
Windows Users
Icons
ImageMate Windows
Icons
(may vary slightly with
OS version)
Slot#
• Safely eject the memory card from the ImageMate.
1) Close all open applications, programs and windows that may be accessing the Removable Disk memory card.
NEVER remove the media when the LED is ACTIVE, FLASHING, BLINKING.
2) Right-click on the Removable Disk icon.
3) Left-click select EJECT (Windows 98/SE*, 2000** and Me)
*Windows 98/SE > By Default, WRITE BEHIND CACHING is disabled, EJECT not available. When WRITE BEHIND
CACHING is enabled, left click select EJECT.
** Windows 2000 > Administrative Privileges REQUIRED to use the EJECT feature.
4) Safely remove the memory card from the ImageMate Dual reader.
Media
LED 1
Media
LED 2
Figure 1.3
Removable
Disk (E:)
Slot 2 is always CompactFlash
Slot 2
Slot 1 is SmartMedia, Memory Stick,
5
Power
LED
Slot 1
Removable
Disk (F:)
Secure Digital or MultiMediaCard
