9. Signal

Module
Module 16
9 Signal

9.1 LEDs for each output

Green
Off

9.2 Status LED

Lights up green every five seconds
Lights up red every five seconds
Flashes green/red
Flashes red
30 / 132
Address
F
1. Press the sides of the transparent inlay together.
2. Remove the transparent inlay.
3. Use a screwdriver to configure the address as per
the table.
4. Insert the transparent inlay again.
Each of the eight outputs has an assigned LED. This
LED indicates the output's status.
There is also a three-colour RGB LED which indicates
the SmartOutput module's status.
Output closed
Output open
Communication with SmartRelay
OK
Communication with SmartRelay
disrupted (e.g. bus line busy due to
communication by other modules)
Communication is taking place
with SmartRelay
Supply voltage too low
