Display and Control Elements

1) Current converter
2) Movable jaw
3) Range selection switch
4) Digital Display
5) "VΩ" input socket
6) "COM" input socket
7) MIN/MAX key
8) AC/DC switch key
9) Data Hold

Carrying - out current measurements

When testing any current measurements only the handle of the
instrument may be touched.
Prior to usage and measurement check that the instrument is
in perfect working order, for example at a known current sour-
ce.
Select the measuring range prior to connection of the instru-
ment to the UUT.
12
9
8
7
6
1
2
3
4
5
