$QV.KOXVVGLDJUDPP IÖU GLH ;33 6RQGH
NON - HAZARDOUS LOCATION
NON - HAZARDOUS LOCATION
MILLTRONICS
CONTROLLER
MILLTRONICS
CONTROLLER
NOTES :
1) THE XPP-5 CABLE MUST BE TERMINATED IN AN AREA EXTERNAL
TO HAZARDOUS LOCATIONS, CLASS I, DIV 1, GR.
2) A SEAL SHALL BE INSTALLED WITHIN 50 mm OF THE XPP-5 CONDUIT HUB
FOR CLASS I, DIV. 1 HAZARDOUS LOCATION ONLY.
3) INSTALLATION SHALL BE DONE IN ACCORDANCE WITH
CANADIAN ELECTRICAL CODE PART 1 REQUIREMENTS.
4) DO NOT EXPOSE THE XPP-5 TO DIRECT SUNLIGHT, OTHERWISE
PROVIDE SUN SHIELD.
5) STATIC HAZARD, DO NOT RUB WITH DRY CLOTH.
N. T. S.
B. GRAY
R. CLOSS
S. NGUYEN
6HLWH
HAZARDOUS LOCATION
HAZARDOUS LOCATION
CLASS I, DIV 1, GROUPS A,B,C,D
CLASS I, DIV 1, GROUPS A,B,C,D
CLASS II, DIV 1, GROUPS E,F,G
CLASS II, DIV 1, GROUPS E,F,G
METAL CONDUIT
CERTIFIED
CONDUIT
SEAL
FITTING
JUNCTION BOX
CLASS I & II
CERTIFIED
CONDUIT
SEAL
FITTING
A,B,C,D
& CLASS II, DIV 1, GR. E,F,G.
XPP-5
INTERCONNECTION DIAGRAM
0)$ S r %(75,(%6$1/(,781*
CERTIFIED
CONDUIT
SEAL
FITTING
XPP-5
METAL CONDUIT
CERTIFIED
CONDUIT
SEAL
FITTING
REVISED HOUSING THREADS
2
PER ECN #00-000-0-0070
REVISED CABLE AND TERMINAL CONNECTOR
1
PER ECN #00-000-0-0037
0
FOR CONSTRUCTION
2365013102
23650131
1=1
XPP-5
JULY
RWG
SN
11/00
APRIL
RWG
SN
18/00
MARCH
RWG
SN
27/00
2
1
1
0/ ,)0
