OSD Functions
ICON CONTROL
Adjust the left and right margins for more
PINCUSHION
convex or more concave margins.
Adjust the trapezoid of the screen by
TRAPEZOID
moving the lines inward or outward.
Adjust the parallelogram when the screen
PARALLELOGRAM
is leaning left or right.
Adjust the side balance when the sides of
PIN BALANCE
the screen are bowed towards left or right.
Adjust the pin corner top when the top
T. PIN CORNER
sides of the screen are bowed (Optional).
Adjust the pin corner bottom when the
B. PIN CORNER bottom sides of the screen are bowed
(Optional).
Adjust the position of the display
H. CENTER &
horizontally (left or right) and vertically
V. CENTER
(up or down)
Choose different preset color
COLOR TEMP temperatures or set your own customized
color parameters.
RED GAIN Adjust the red gain.
Adjust the green gain.
GREEN GAIN
BLUE GAIN Adjust the blue gain.
H. SIZE &
Adjust the width (horizontal size) and the
height (vertical size) of the display.
V. SIZE
Degaussing keeps the monitor free from
unwanted magnetism that can result in
DEGAUSS
color impurity.
English - 7
FUNCTION
.
ICON CONTROL
Display horizontal & vertical frequency
STATUS
and polarity.
Adjust the horizontal picture moire
H. MOIRE
cancellation.
Adjust the vertical picture moire
V. MOIRE
cancellation.
Select language for OSD (5 languages).
LANGUAGE
Reset the screen to the Factory Preset
RECALL
Display Settings.
Self Diagnosis
When the monitor doesn't display, if you press any key, Self
Diagnosis screen is displayed. Self Diagnosis function checks
if the status of the monitor is No Signal or Out of range.
No Signal screen is displayed when
the D-Sub signal connector is not
connected or the status of the monitor
is on DPMS mode.
Out of Range screen is displayed
when the applied frequency is under
or over normal range.
Normal range
H : 30 - 54 KHz
V : 50 - 160 Hz
