Kröber O2 Gebrauchsanweisung Seite 79

1
Fig. 21: Humidifier bracket
Nasal cannula
Fig. 22: Connection to the nasal cannula
EN
9 Stand the humidifier into the bracket
10 Plug the FireSafe Nozzle in oxygen
Oxygen hose
11 Connect the other terminal to the
Kröber O2 - Kröber O2 Vers. 4.0
(1).
NOTE!
The bracket has the function of
preventing the humidifier from falling
over. It is therefore recommended to
mount the bracket to a wall, a
cupboard, etc.
flow direction into the nasal cannula.
ATTENTION!
Observe flow direction indicated
by the arrow!
ATTENTION!
For the best protection of the
patient, place the FireSafe Nozzle
in the oxygen tubing routing as
close to the patient as possible!
short oxygen tubing (0.33 m).
Taking into service
79
