HiCap, XP5 XS, and FlatCap XS Power Supplies
5 P ow er sup p l y I ns ta lla t io n
Power supplies should be installed on an equipment rack intended for the purpose in
their final location before connecting cables or switching on. ensure that power amplifiers
are switched off and the preamplifier volume is turned down before power supplies are
switched on. Connection diagrams will be found in the appropriate product owners
manual.
many power supplies are heavy and care should be taken when lifting or moving them.
make sure that the surface on which they are to be placed can support their weight.
5 . 1 HiCap re ar
mains input
and fuse
5 . 2 XP 5 X s re ar
mains input
power
switch and fuse
5 . 3 F la t Cap X s re ar
power mains input
and fuse
switch
e4
socket 1
socket 2 socket 3
note: The XP5 XS can be used to power the CDS3, CDX2,
HDX, DAC, NDX and ND5 XS. It cannot be used to power
the CD555.
socket 1, 2 & 3
ch1
ch2 nc
-ve
socket 4
power
out A
socket 4
+ve
ch1
+ve
ch2
-ve
multiple power output
signal signal
out A out C
signal
power
out B out B
Power out signal out
a & B a, B, C & D
+ve
+ve
ch2
ch2 ch1
-ve
-ve
signal
out D
ch1
nc
