5 5 5 PS, S upe r C a p a nd X P S P ower Su ppli es
4 In sta lla tion
Power supplies should be installed on an equipment rack intended for the purpose in
their final location before connecting cables or switching on. ensure that power amplifiers
are switched off and the preamplifier volume is turned down before power supplies are
switched on. The power buttons are located on the front panel. Connection diagrams will
be found in the appropriate product owners manual.
some power supplies are heavy and care should be taken when lifting or moving them.
make sure that the surface on which they are to be placed can support their weight.
4 . 1 5 5 5 P s re ar
mains input
and fuse
4 . 2 s up erCa p re ar
mains input
and fuse
4 . 3 X P s rea r
mains input and fuse
note: The 555 PS can be used to power the CD555, CDS3,
CDX2, HDX, DAC, NDX and ND5 XS. In the case of the CDS3,
CDX2, HDX, DAC, NDX and ND5 XS only Output 1 is used.
+ve
ch2
note: The XPS can be used to power the CDS3, CDX2,
HDX, DAC, NDX and ND5 XS. It cannot be used to power
the CD555.
socket
2
socket
1
socket 1 socket 2
+ve
ch1
+ve
nc
-ve
NAC 252
only
socket socket
NAC 252,
3 5
SuperLine
socket
or SNAXO
4
only
socket 3, 4 & 5
+ve
ch1
nc
ch2 nc
-ve -ve
multiple power output
e3
