24 | English

Blade Maintenance

Always clean the cutting blades after operation
and lubricate with Bosch Maintenance spray.
During longer cutting jobs, we recommend peri-
odically lubricating the cutting blade with Bosch
Maintenance spray.
Visually check the condition of the cutting edges
of the cutting blade.
Ensure that the cutting blade is covered with the
blade guard supplied when not in use.
Changing the Blade (see figures E
Warning! Switch off before adjusting or
cleaning. The blades continue to move for a
few seconds after the garden product is
switched off.
Caution! Do not touch the moving blades.
Always wear protective gloves when using,
adjusting or cleaning the garden product.
Blade Removal
Push the SDS drive cover release button
E F
15 and slide the SDS drive cover 7 towards the
On/Off switch 5. Lift away from the housing.
Lift the blade 1 out.
G
Blade Fitting
Fit the blade 1 as shown aligning the holes in
H
the blade onto the drive pins and locate the
blade 1 under the retaining rib in the rear corner
of the housing.
When refitting the SDS drive cover 7 ensure
I
all 4 location legs are inside the housing prior to
sliding cover into place.
Slide the SDS drive cover 7 back towards the
J
blade 1 to secure.
After Usage/Storage
Warning! Switch off before adjusting or
cleaning. The blades continue to move for a
few seconds after the garden product is
switched off.
Caution! Do not touch the moving blades.
Always wear protective gloves when using,
adjusting or cleaning the garden product.
F 016 L70 578 | (22.12.08)
Clean the exterior of the garden product thor-
oughly using a soft brush and cloth. Do not use
water, solvents or polishes. Remove all debris.
Ensure that the cutting blade is covered with the
blade guard supplied when not in use.
Store the garden product in a secure, dry place
out of the reach of children. Do not place other
objects on top of the garden product.
Accessories
Grass shear blade . . . . . . . . . . . 2 609 002 039
Shrub shear blade . . . . . . . . . . . 2 609 002 040
J)
–
Handle . . . . . . . . . . . . . . . . . . . . 2 609 002 041
Lubricant spray, 250 ml . . . . . . . 1 609 200 399
After-sales Service and Customer As-
sistance
Our after-sales service responds to your ques-
tions concerning maintenance and repair of your
product as well as spare parts. Exploded views
and information on spare parts can also be
found under:
www.bosch-pt.com
Our customer consultants answer your ques-
tions concerning best buy, application and ad-
justment of products and accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: SPT-Technical.de@de.bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
