3. PRODUCT OVERVIEW

3.4 OVERVIEW OF CONNECTIONS

Ethernet port
P1 port
Connection
DC-protection
module
DC-protection
module
Phase 3
Phase 2
UTP data cable inlet
with rubber seal
Inlet for
power cable
If connecting to a 3-phase grid without neutral; only install 1-phase and connect one of the two other phase
wires in the neutral wire connection on the terminal block.
INSTALLATIEHANDLEIDING – P10
INSTRUCTION MANUAL – P10 | P10
INSIDE
VERSION 0129NM02INT01
0382NM02INT03
Terminal block
Phase 1
Neutral
Earthing
Earthing pole
Earthing point for
pole mount
UTP data cable inlet
with rubber seal
Power cable clamps
