Temperature sensor installation

Install the temperature sensor with cable ties with the heat
conducting paste and aluminium tape.
Then insulate with supplied insulation tape.
NOTE
Sensor and communication cables must not be placed
near power cables.

Program settings

Select "Service" in menu 8.1.1 to gain access to menus
9.0 and the sub-menus.
Then select "Heating", "Heating + Cooling" or "Cooling"
in menu 9.3.4, "Heating system 2". Menu 3.0 and its sub-
menus become accessible.
In the sub-menus the curve co-efficient 2, offset heat
curve 2 and min- and max levels for the flow line temper-
ature 2 are set in the same way as heat system 1 under
menu 2.0.
See "Installation and Maintenance Instructions" for NIBE
SPLIT.
