PAD MONITORING
Your Tomy Movement Sensor Pad Monitor has been carefully designed to sit underneath the mattress of your cot or
Moses basket to detect all movements baby makes and to emit an alarm when no movement is detected after 20
seconds.
Every movement is accompanied by a soft click and an illuminated visual indicator. Should no movement be detected
on the Movement Sensor Pad for 20 seconds, a continual beep alarm will be activated.
Pad Sensor Input
Pad Sensor
Volume Control
Pad Sensor
Movement Indicator
Positioning the Sensor Pad
The Tomy Movement Sensor Pad sits underneath the mattress of your cot or Moses basket as shown (below).
Once you have chosen baby's sleeping area, position the Movement Sensor Pad to lie directly underneath her torso.
IMPORTANT! The Movement Sensor Pad must rest on a completely at, rigid surface and must be placed with the
'Tomylogo' side facing up. Ensure that no bedding is positioned between the mattress and the Movement Sensor Pad.
For best performance we recommend covering the base of slatted based cots with a thin layer (6mm) of plywood to
ensure an even surface. Ensure any loose cable is wrapped and tied to avoid possible entanglement. From the cot,
run the cable along the oor ensuring it is kept out of baby's reach; excess cable should be spooled around the cable
tidy.
Pad Sensor
Pad Sensor
Movement Indicator
Keep cot sides & ends at
least 38cm (15 inches)
from adjacent bedroom
furniture
Movement Sensor Pad
The Movement Sensor Pad can be used remotely through your Parent Unit or locally as a standalone Movement
Monitor.
Remote Monitoring
Ideal for monitoring baby from the nursery, connect the Movement Sensor Pad to the Baby Unit as shown above,
your Parent Unit will emit an extended beep indicating connection; all movement monitoring has now transferred
through to your Parent Unit via the soft click and illuminated
Fail Safe – In the unlikely event of loosing connection with the Baby Unit, your Parent Unit will again emit an
extended 'beep' at which time all movement monitoring and alarms will revert back to the Baby Unit.
Local Monitoring (movement only)
Suited for when Baby is in the bedroom with you and you have no need for remote or audio monitoring. Connect the
Movement Sensor Pad as shown (above). Activate the Baby Unit by pressing and holding the
illuminate green and the
button shall illuminate red. Movement monitoring shall commence.
Whilst monitoring this way, the soft clicks and alarm shall emit through the baby only (having no need for your
Parent Unit, at this stage). The Nightlight and Lullabies have also been designed to work independently, activate by
pressing the respective icons;
.
When the times comes and you wish to use the full features of your monitor. Deactivate the Baby Unit and reactivate by
pressing and holding the
button until it illuminates green then follow the 'remote monitoring' instructions (above).
Volume Adjustment
For safety reasons the alarm volume can not be adjusted. The volume of the movement sensor clicks are independent
from the Parent Units audio monitoring volume and can be adjusted by sliding the switch on the underside of the Baby
Unit.
Pad Sensor
Volume Control
Testing
Before every use we recommend carrying out the following checks with the Pad in the cot or Moses basket. Firstly
tap the mattress, at which time your Parent or Baby Unit shall emit a soft click and the
Green. Follow this by leaving the Pad to stand untouched for 20 seconds, then the alarm shall sound and the
indicator shall illuminate red. Simply deactivate the alarm by tapping the mattress again.
icon.
icon, it shall
Movement Click Volume Adjustment
Mute (Visual Indisctaor (
) & alarm only)
Low
High
indicator shall ash
EN
