required according to the food to be
prepared.
-Cut all foods into pieces (Sinewless,
boneless and fatless meat is
recommended, approximate size :20 mm x
20 mm x 60 mm) so that they fit easily into
the hopper opening.
- Turn the appliance on using the on/off
switch.
- Select the desired speed.
-Feed foods into the hopper plate. Use for it
only the food pusher.
accessories:
Cutting plates (I)
-These cutting plates allow mincing meat
with a coarser or finer texture depending on
the size of the holes in the disc.
-Press the fasten button hold the head and
insert it into the inlet(when inserting pls pay
attention the head must be slanted as per
arrow indicated on the top,see (fig.1),then
move the head anticlockwise so that the
head being fastened tightly .(fig.2)
-Insert the endless screw through the outlet
mouth of the mincing head. ( fig. 3 )
-Position the cutting blade in the endless
screw with the cutting edge pointing
towards the endless screw. ( fig. 4 )
-Insert one of the three cutting plates in
the endless screw, fitting the outlets of the
cutting plate in the notches of the outlet
mouth edge of the mincing head. ( fig. 5 )
-Screw the fasten rim tightly in the outlet
mouth of the mincing head turning clock-
wise to fit the endless screw, blade and the
cutting plate. ( fig. 6 )
Manual Savoy.indd 14
-Position the tray at the top of the mincing
head.
Nozzle for filling sausages (L)
- Insert the mincing head into the motor
body securing with the clamp for the blade
holder ( fig. 1 ).
- Insert the endless screw through the outlet
mouth of the mincing head. ( fig. 3 )
-Position the cutting blade in the endless
screw with the cutting edge pointing
towards the endless screw. ( fig. 4 )
-Insert the cutting plate with largest holes
in the endless screw, fitting the outlets of
the cutting plate in the notches of the outlet
mouth edge of the mincing head. ( fig. 5 )
-Insert the nozzle for filling sausages via the
sealing ring. ( fig. 7 )
-Screw the fasten rim tightly in the outlet
mouth of the mincing head turning clock-
wise to fit the endless screw, blade and the
screen with holes ( fig. 6 )
-Position the tray at the top of the mincing
head.
accessory for Kebbe (M)
- Insert the mincing head into the motor
body securing with the clamp for the blade
holder ( fig. 1 ).
- Insert the endless screw through the outlet
mouth of the mincing head. ( fig. 3 )
- Insert the accessory for base Kebbe in the
endless screw and position the other Kebbe
accessory on top, fitting the outlets in the
edge notches of the filling mouth. ( fig. 8)
-Screw the fasten rim tightly turning
clockwise to fit the accessories for Kebbe in
the endless screw. ( fig. 9)
