ENGLISH
E. Connect the speaker system to an audio source:
a. If your Audio Source is a DVD-Player, amplifier, etc. with 6x RCA output, use
the connection diagram below:
To Front-Right Output of source
To Rear-Right Output of source
To Subwoofer Output
of source
To Center Output
of source
To Rear-Left Output of source
To Front-Left Output of source
b. When the source is a computer with 3,5mm Jack input(s), you need to use the
adapter cables. The adapter cables will convert the 6x RCA connector to 3x
3,5mm Jack connector. The 3x 3,5mm Jack connectors can be used for your
soundcard:
RCA Jack In
RCA Jack In
15
3,5mm Jack Out
