ENG
INSTALLATION FOR DRIPPER SET
1. Screw the timer inlet securely
to a garden tap.
2. Place the filter in the inlet of
the pressure reducer.
3. Attach the pressure reducer
to the timer.
a. If you want to construct
one dripper system,
use the single output
connector.
b. If you want to construct
two dripper systems,
use the double output
connector.
4. You can start using the timer
once the dripper set is
attached.
5. Set the desired watering time
by setting the FREQUENCY and
RUN TIME. Instructions for this
can be found on page 6.
6. Turn on the tap.
7. Once the set watering time has ended, the timer
switches off the water flow.
8. Turn off the tap.
4
1
2
3
2a
See the instructions for
Rustas dripper set.
2b
