During Use - Silva ALPHA Bedienungsanleitung

ergonomic head set
The head set is ergonomically shaped to give comfortable fit. Use the 3 Velcro
adjustments to fit it perfectly to your head.
Attach the headlamp in the head set by simply sliding the headlamp foot into the
snap-in socket.
To remove, press the push button on the socket and move the headlamp up and out.
Bike handle bar attachment
Included in Alpha 6, optional accessory for Alpha 4 and 2.
The bike handle bar attachment is developed for use on bike handlebars with a di-
mension between 25 and 32 mm. Included with the bike handle bar attachment are
3 rubber inserts. Use these to ensure the correct fitting for your bike and tighten the
bottom screw to secure it on to the handle bar.
Attach the headlamp in the bike handle bar attachment by simply sliding the headlamp foot into the snap-in
socket.
To remove, press the push button on the socket and move the headlamp up and out.
Helmet attachment
Included in Alpha 6, optional accessory for Alpha 4 and 2.
The helmet attachment comes with pre mounted adhesive on the back for easy
mounting on any helmet. The adhesive is a Polyethylene foam tape developed to not
damage or cause any type of weakness to plastics.
To mount the helmet attachment, remove the protective film covering the adhesive. Make sure the surface
of the helmet is clean and dry. Press the bracket onto its correct position.
If you do not want to use the adhesive on your helmet the attachment is prepared for mounting with 2
straps on the sides. (Not included)
Attach the headlamp in the helmet attachment by simply sliding the headlamp foot into the snap-in socket.
To remove, press the push button on the socket and move the headlamp up and out.
flexible battery carrying
The Alpha headlamp is designed so that the battery could be carried in multiple
ways; for example in a battery carrier on your back, on the bike frame, in your belt or
backpack etc.
On Alpha 4 and Alpha 2 the battery can also be carried on the back plate of the
ergonomic headset (extension cable not needed).
Use the extension cable located in your carrying case.
Use the unique battery carrying case that allows for multiple attachments.

DurIng use

Battery indication (alpha 6 and alpha 4)
When you connect the battery to the headlamp the current battery status will be shown in the upper left
corner of the headlamp lens. The battery status is divided into 4 different levels:
1. green leD = battery capacity 60 to 100%
2. orange leD = battery capacity 40 to 60%
3. red leD = battery capacity 20 to 40%
4. red leD flashing = battery capacity 0 to 20%
The battery indication will be shown for 5 seconds or until the headlamp is switched on.
5
