Plantronics IP40 Anschluss Und Installation Seite 2

12
4
1. Headset port
2. Ethernet to PC port
3. Ethernet to network port (PoE)
4. Ethernet cable to PC
1
(optional – not supplied)
5. Ethernet cable to network (supplied)
6. Power socket
7. Power adapter (not supplied)
8. Volume up/down control button
9. Mute button including indicator LED
10. Call answer button including indicator LED
11. Power indicator
12. Quick Disconnect™ (QD)
13. Network Ethernet port
Features
6
13
5
2
3
7
