Client Mode; Hardware Information - TP-Link AP series Schnellstartanleitung

English

Client Mode

The AP device functions as a wireless adapter to connect the wired device (e.g. Xbox/TV) to a wireless
network.
Internet
1. Connect the AP device according to steps A and B in the diagram.
2. Turn on the power and wait until the Power ( ) LED is lit and stable.
3. Connect your computer or smart device to the AP device via a wired or wireless
connection. The default SSID and wireless password are printed on the product
label.
4. Launch a web browser and enter http://tplinkap.net, then log in using admin (all
lowercase) for both Username and Password.
5. Click Quick Setup, then select Client mode and click Next. Follow the step-by-
step on-screen instructions to complete the configuration.
Now, connect your wired-only device to the AP device using an Ethernet cable.

Hardware Information

LED
LED
Power
Host AP's SSID
Host AP
Status
On
Off
Blinking
A
Indication
The device is on.
The device is off.
The device is initializing or upgrading.
8
Qther
Device
Or
TV
Or
B
