Kenwood CCD-2000 Bedienungsanleitung

Universal rückfahrkamera
Vorschau ausblenden Andere Handbücher für CCD-2000:

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 14
CCD-2000
UNIVERSAL REAR VIEW CAMERA
INSTRUCTION MANUAL
CAMERA DE VUE ARRIERE UNIVERSELLE
MODE D'EMPLOI
UNIVERSAL RÜCKFAHRKAMERA
BEDIENUNGSANLEITUNG
UNIVERSELE ACHTERUITRIJCAMERA
GEBRUIKSAANWIJZING
TELECAMERA PER RETROMARCIA UNIVERSALE
ISTRUZIONI PER L'USO
CÁMARA DE VISTA TRASERA UNIVERSAL
MANUAL DE INSTRUCCIONES
CÂMARA TRASEIRA UNIVERSAL
MANUAL DE INSTRUÇÕES
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best
performance from your new Rear View Camera.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the
warranty card, and in the space provided below. Refer to the model and serial numbers
whenever you call upon your Kenwood dealer for information or service on the product.
Model CCD-2000 Serial number
US Residence Only
Register your Kenwood product at
www.Kenwoodusa.com
© B64-3673-00/00 (W)(A)
Register Online
