7. Installation
7.E Boiler control system installation
Mini Bio boiler control system includes a wall mounted Platinum Bio
control.
Caution!
Platinum Bio control system installation method must guarantee
rigid installation and installation position must ensure ergonomic
use (e.g. by providing suitable installation height for easy
installation) and easy access.
The electrical system connecting Platinum Bio control system and
Mini Bio boiler must be protected against damage caused by the
use of a device (boiler) by installation on the flat surface (wall) with
cable mounting brackets - avoid hanging cables which may obstruct
control system access and cause health hazard.
Fig. Mini Bio Luxury boiler control system installation / removal
Experts in heating
7.F Mini Bio Luxury boiler control system
installation / removal
Mini Bio Luxury control system includes a distribution board and
a control panel installed on the front boiler insulation.
