4. Mini Bio/Mini Bio Luxury boiler design (as a complete heating device)
4.D Fuel feeder unit
A locally manufactured fuel feeder is a dedicated system
conveying fuel from the storage hopper to the burner.
1. storage hopper
2. feeder
3. feed duct
4. feed screw
All electrical connections must conform
to the general guidelines on wiring systems,
see section 4.G 'Wiring system'.
Fig. Feeder unit
4.E Storage hopper
Mini Bio/Mini Bio Luxury 10 kW and 20 kW boilers are fitted with a
220 l and 240 l storage hopper, respectively, compatible with biofuels
(wood pellets and oats).
Fig. Storage hopper
