AXIS Q6055-C PTZ Dome Network Camera
1
Heat sink cover
2
Screw T30 (3x)
3
Fan cables
4
Heat sink
4. Remove dust and specks of dirt by blowing on the heat sink, for example by using a
small air compressor or a can of compressed air. The heat sink may also be rinsed with
pure water.
5. Put the heat sink cover back in its original position and tighten the screws (torque
2.4 ±0.2 Nm).
6. Put the sunshield back in its original position and tighten the screws (torque 1.2 ±0.1 Nm).
7. Connect the multicable to the connector on the camera.
