Technical Specifications - Beyerdynamic MCE 72 Produktinformation

Model Description . . . . . . . . . . . . Order #
WS 101 Wind screen,
colour: charcoal-grey. . . . . . 111.244
MAV 800 Clip 3/8" for hanging
installations of microphones
(from the ceiling) . . . . . . . . 448.133

Technical Specifications

Transducer type . . . . . . . . . . . Condenser
Operating principle . . . . . . . . Pressure gradient
Frequency response . . . . . . . . 60 - 20,000 Hz
Recording . . . . . . . . . . . . . . . . XY stereophony
Polar pattern . . . . . . . . . . . . . 2 x cardioid, principal
Open ciruit voltage
at 1 kHz . . . . . . . . . . . . . . . . . 12 mV/Pa
Nominal impedance . . . . . . . . 180 Ω
Load impedance. . . . . . . . . . . > 1 kΩ
Max. SPL at 1 kHz. . . . . . . . . . 123 dB
Signal-to-noise ratio
rel. to 1 Pa . . . . . . . . . . . . . . . approx. 60 dB
A-weighted equivalent SPL . . approx. 26 dB
Power supply . . . . . . . . . . . . . 1.5 V battery
Current consumption . . . . . . . 12 mA
Operating time with battery
type LR 6 (2300 mAh). . . . . . . approx. 75 hrs.
Output . . . . . . . . . . . . . . . . . . unbalanced,
Connection. . . . . . . . . . . . . . . 5-pin XLR male
Connecting cable
Input. . . . . . . . . . . . . . . . . . . . 5-pin XLR female
Output . . . . . . . . . . . . . . . . . . 3.5 mm Stereo jack
Dimensions
Length . . . . . . . . . . . . . . . . . . 196 mm
Diameter . . . . . . . . . . . . . . . . 25 mm
Weight (without battery). . . . 175 g
(back electret)
axis angle 120°
(Mignon AA)
capacitor decoupled
Pin 1 = Shield
Pin 2 = AF- left
Pin 3 = not connected
Pin 4 = AF- right
Pin 5 = not connected
plug
13
