NGS Nomad Bedienungsanleitung Seite 5

User's Manual
4. The "Volume" Option: This is to adjust the alarm
volume from 0 - 16. The volume 0 is mute and
the volume 16 is the loudest. The alarm volume
default is at volume 16.
5. The settings will not be saved and activated
until the 'Save' option item has been selected.
If you exit settings saving, a pop-up screen will
inform the user as below.
Figure 6: Notification of alarm without Saving
settIng Up the Internet radIo
In the first time using the NOMAD, the Internet
connection must be setup to access the Internet.
Please follow the below 2 procedures to setup the
access point:
· Select the WLAN region. Choose your region in
the list.
· The Internet Wizard will guide you through the
setup of the network once you have chosen the
region. The radio has been configured to run the
Internet Wizard automatically when entering the
Internet Radio mode if a connection has not been
made before.
Alternatively, you could run the Internet Wizard to
connect to a different Wi-Fi network by choosing
the "Internet Setup" in the "System Setup" option
in the main menu.
The Internet setup menu allows selecting either:
· Help you setup the Wi-Fi access point or;
· View and edit the current Wi-Fi settings.
To setup the internet radio by using the Internet
Wizard:
1. Select the "Wizard" in the Internet Setup.
2. Select the WLAN region in which the radio is
located.
3. The Wizard will automatically scan for all avail-
able Wi-Fi networks.
4. Select your desired network with the rotary
control key. There are three options:
· [Rescan] Rescan for all possible network;
· [Manual config] Set up the wireless configuration
manually.
5. If an unlocked network is available, the radio
will automatically connect to the network.
"Connected" will be shown on the screen once
the radio successfully enters Internet.
6. If the network is with security, input the pass-
word of the access point to connect the network.
Use the rotary Control by turning left or right to choose
the different sets of characters along the row of characters.
Press the Rotary Control to select the flashing cursor.
Choose the '<' symbol = back space
the 'ø' symbol = enter (this must be selected once
the password has been inserted)
the 'C' symbol = cancel
7. Users can edit their Wi-Fi settings by selecting
the System setup > Internet setup > Manual
settings.
8. Selecting View settings allows you to access
other Wi-Fi settings. These are :
· Active adapter, which displays the current con-
nection being used to connect to the Internet,
· MAC address,
· DHCP status
· PC settings
· SSID
· IP settings, which displays the IP address, the
subnet mask and the gateway address.
English
5
