No. Description
1
Internal Power Header (ATX19V_IN1)
2
USB 2.0 Header (USB6)
3
SATA3 Connector (SATA_1)
4
Chassis Fan Connector (CHA_FAN1)
5
Consumer Infrared Module Header (CIR1)
6
SATA3 Connector (SATA_0)
7
USB 2.0 Header (USB4_5)
8
SATA Power Connector (SATA_POW1)
9
Monitor Switch Header (MONITOR_SWITCH1)
10
System Panel Header (PANEL1)
11
Backlight Power Jumper (BKT_PWR1)
12
Panel Power Jumper (PNL_PWR1)
13
LVDS Connector (LVDS1)
14
2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
15
Backlight Control Header (BLT_VOL1)
16
COM Port Header (COM1)
17
USB 2.0 Header (USB2_3)
18
CPU Fan Connector (CPU_FAN1)
19
Front Panel Audio Header (HD_AUDIO1)
20
Digital MIC Header (DMIC1)
21
SPDIF Out Connector (HDMI_SPDIF1)
22
3W Audio AMP Output Wafer Header (SPEAKER1)
23
Analog Surround Audio Header (HD_AUDIO2)
24
Home heater PC Header (HTPC1)
25
Clear CMOS Jumper (CLRCMOS1)
26
LPC Debug Header (LPC1)
2
