Keep away children and amateurs!
By operating an amplifying system, you can produce excessive sound pressure levels that may
lead to permanent hearing loss.
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
OPERATING DETERMINATIONS
This device is a professional system-controller. This product is allowed to be operated with an alternating
current of 115/230 V, 50/60 Hz and was designed for indoor use only.
Do not shake the device. Avoid brute force when installing or operating the device.
When choosing the installation-spot, please make sure that the device is not exposed to extreme heat,
moisture or dust. There should not be any cables lying around. You endanger your own and the safety of
others!
The ambient temperature must always be between -5° C and +45° C. Keep away from direct insulation
(particularly in cars) and heaters.
The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
This device must only be operated in an altitude between -20 and 2000 m over NN.
Do not operate the device in extremely hot (more than 30° C) or extremely cold (less than 5° C)
surroundings. Keep away from direct insulation (particularly in cars) and heaters.
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, etc.
DESCRIPTION
Features
Digital system-controller
• 4 inputs and 8 outputs with flexible signal routing
• 32-bit floating point DSP
• 96 kHz sampling rate
• 24 bit A/D-converter
• 6 fully parametric equalizers per input and output
• Slopes up to 48 dB/octave
• Large display
• 30 user programs can be memorized
HEALTH HAZARD!
• Up to 450 ms signal delay for the inputs and
outputs adustable
• Delay displayed in milliseconds, meters, feet and
frame/second
• Output limiter with ajustable limits and automatic
attack and release settings as overload protection
for your amplifying system
• Lock-function for protecting the program settings
• Phase Invert switch per output
• Digital adjustment of the input gain ± 15 dB
