AC25
Accessories PLS
PLSB Control unit Basic
PLSAC Control unit Competent
PLSRTX External room
temperature sensor
SIRECJ4 RJ11 coupler (4/4)
SIRECJ6 RJ12 coupler (6/6)
SIRECC403
SIRECC405
RJ11 modular cable (4/4)
SIRECC410
SIRECC415
SIRECC603
SIRECC605
RJ12 modular cable (6/6)
SIRECC610
SIRECC615
PAMLK Motor alarm board
Control valves for water systems (optional)
Type Connection
VOS15LF DN15
VOS15NF DN15
VOS20 DN20
VOS25 DN25
VOT15 DN15
VOT20 DN20
VOT25 DN25
VAT
Incl. control unit PLSUB1 and 5 meter modular
cable with RJ12 quick connect.
IP30
Incl. PLSUA1 control unit, box cover, PLSC1X hub
unit, PLSDC door switch, and 2 modular cables
with RJ12 quick connects (1 pc 3 m, 1 pc 5 m).
IP30
70x33x23 mm
Used to join together two RJ11 or RJ12 connec-
tors.
Length 3 m
Length 5 m
Length 10 m
Length 15 m
Length 3 m
Length 5 m
Length 10 m
Length 15 m
Provides a potential free alarm connection
when thermal contact is triggered in the motor.
Installed in the air curtain.
VOT
31
SIRECJ4 / SIRECJ6
VAT
VOS
PLSB
PLSAC
PLSRTX
SIRECC
PAMLK
